| Capacities | |
| Shaft Rotation | Clockwise or Counterclockwise |
| Maximum Speed | 1800 rpm |
| Dimensions | |
| Drive Shaft Dia. | 0.625" (5/8") [15.88mm] |
| Drive Shaft Length | 1.875" (1-7/8") [47.63mm] |
| Center of Shaft to Base | 3.500" (3-1/2") [88.90mm] |
| Power | |
| Horsepower | 1/2 |
| Armature Voltage | 90 VDC |
| Amps @ Full Load | 5.2 |
| Starting Torque | 1.5 ft·lbs (17.5 in·lbs) [0.2kg-m] [2N-m] |
| Features | |
| Enclosure Type | TENV |
| Installation | |
| For Motor Frame | 56C |
| Support | |
| Phone and email Support | |
| Warranty | |
| Condition | |
| Product Condition | |
